Mersen/Ferraz Shawmut AJT9 Amp-Trap 2000 Class J Time-Delay Fuse, 9A 600V - Lot of 14

This lot contains fourteen (14) high-performance AJT9 (9 Amp) Class J fuses manufactured by Mersen (formerly known as Ferraz Shawmut). As part of the Amp-Trap 2000® series, these fuses provide superior "No Damage" IEC Type 2 protection for critical industrial components.

Advanced Protection: Engineered with time-delay characteristics specifically for handling high motor starting currents and transformer inrush without nuisance tripping.

Highly Current-Limiting: Effectively restricts peak let-thru current to protect downstream equipment, making it the most current-limiting UL class fuse available.

Space-Saving Design: Features a small footprint that requires only half the mounting space compared to standard 600VAC Class RK fuses, allowing for more compact control panels.

Industrial Build: Constructed with a fiberglass body for dimensional stability in extreme environments and high-grade silica filler for rapid arc quenching.

Technical Specifications (Per Fuse):

Current Rating: 9 Amps.

Voltage Rating: 600VAC / 500VDC.

Interrupting Rating: 200kA at 600VAC (Self-certified up to 300kA).

Dimensions: 0.81" Diameter x 2.25" Length.

Standards: UL Listed to Standard 248-8 and CSA Certified.

Applications: Ideal for motor circuits, transformers, mains, feeders, branch circuits, and general loads.
